ULTRASONIC THICKNESS GAUGES


NEW! Ultrasonic Thickness Gauges with A & B Scan and Thru Coating Capability!
Model No. UTG-4000
Utilizing color waveform A-scan and time based B-scan for absolute correctness, this new state of the art thickness gauge is packed with useful features allowing users to be confident of the displayed values on the most critical of applications.

utg-2650 Test steel thickness from 0.01" and up!
Model No. UTG-2650

Ultra Precise! The UTG-2650 is a versatile ultrasonic thickness gauge that reads out in 0.0001” resolution and  includes 5Mhz dual sensor probe, couplant gel and rugged carry case
utg-2800 Most Popular! Loaded with features
Model No. UTG-2800

Our most popular ultrasonic thickness gauge is loaded with features such as scan, Min/Max setting and USB Output and includes 5Mhz dual sensor probe, couplant gel, software and rugged carry case


utg-2850 The New RUGGED Ultrasonic Thickness Gauge
Model No. UTG-2850

Our new Rugged extruded aluminum frame ultrasonic thickness gauge is suited for rough environments such as mining facilities, pipeline, bridge and tower inspections, etc and is packed with features typically found on high end models only


New! Ultrasonic Thickness Gauge w/ thru Coating Capabilities
Model No. UTG-2900

Our new State of the art, digital tester is packed with features typically found on high end models only.
utg-1500 NEW! Economical Thickness Gauge
Model No. UTG-1500
Our most economical ultrasonic thickness gauge includes 5Mhz dual sensor probe, couplant gel and carry case
Accessories for Ultrasonic Thickness Gauges

ULTRASONIC WALL THICKNESS GAUGE MEASUREMENT

The use of Ultrasonic non-destructive testing (NDT) to check material properties such as thickness measurement, is now extensively used in all facets of industry. The ability to gauge thickness measurement without requiring access to both sides of the test piece, offers this technology a multitude of possible applications. Metals, plastics, ceramics, glass and other materials can easily be measured by portable ultrasonic thickness gauges with a common accuracy of.001”.

Ultrasonic thickness gauges measure the thickness of a part by measuring the time sound travels from the transducer through the material to the back end of a part, and then measures the time of reflection back to the transducer. The gauge then calculates the thickness based on the velocity of sound through the material being tested.

A broad variety of piezoelectric transducers, operating at given frequencies are utilized to generate sound when excited. Typically, a 5mhz frequency is standard on all Phase II Ultrasonic Thickness Gauges. Optional transducers are always available for a myriad of applications.

The direct contact method of pulse/echo type ultrasonic thickness gauges requires use of a couplant. Propylene Glycol is common, but many other substances can be used.

Easy to configure and use, many gauges today have the ability to retain memory, output to printers, PC’s, and handheld portable devices. With the combination of an easy menu driven gauge and the data in memory, technician/operators have a world of technology at their fingertips to obtain highly accurate and cost effective measurements for all types of thickness applications.
